Photopolymer
-Photopolymer is a light sensitive resin sheeting that when exposed to high intensity ultraviolet light will harden and change its molecular makeup. We can manipulate what areas get exposed in the Photopolymer via a photographic method that allows us to produce almost any graphic we desire from this material. We offer photopolymer in both interior and exterior varieties.Applique & Raster Braille
Acrylic ADA compliant signs are manufactured using an engraving method. The Braille is produced by drilling precision holes into the acrylic and forcing a very small acrylic balls into the holes to form the Braille characters. The raised letters are produced by gently placing an adhesive backed, 1/32" thick sheet of colored acrylic onto the face of the background panel and engraving the letters and pictograms. After engraving the surrounding material is peeled away leaving the letters and pictograms adhered to the acrylic backer. Because we engrave slightly below the surface of the background, the letters have the appearance of being an integral part of the background acrylic. Also this helps protect the letters from being "picked off" by vandals. This method is often referred to as "Raster Braille" or RLS (Raised Lettering System).Thermoformed Acrylic
Starting with white or clear acrylic sheeting we mold the raised elements into the acrylic thereby forming a one piece ADA compliant sign. Copy, Braille and other graphic elements are integral to the background so there is NO delamination possible. Extremely vandal resistant and 100% exterior rated. This product is painted either top or sub surface with an unlimited color rangepossible. Braille is 100% rounded making it unquestionably ADA compliant.Etched Metal
-Zinc and Magnesium are metals that when chemically etched can be used for Braille signage. This is the gold standard for vandal resistance and durability.
